injection hoses

Choose a product group to go straight to the relevant products.

Match the hose and fittings

The 5 mm system has an 11 mm outside diameter and uses HO-CONNECT 6, HO-END 6 and HO-INJECT fittings. HO-CONNECT 8 and HO-END 8 are also compatible with this system. SMARTHOSE has an 18 mm outside and 8 mm inside diameter; choose HO-CONNECT 8/10, HO-END 8/10 and its dedicated elbows. Select clamps by the outside diameter at the connection.

5 mm system — hoses and fittings

SMARTHOSE 18 mm — hoses and fittings

Clamps and fixings

Connecting the 5 mm hose system

Connecting the 5 mm hose system
1. Braided injection hose · 2. Plain injection hose · 3. Feed hose 6 × 2.5 mm · 4. Clamp 11–13 mm · 5. HO-CONNECT connector · 6. HO-END filling packer. Maximum active hose length: 10 m per section, according to the catalogue.
